Description
|
Overall Length |
34 in |
RAM |
NO |
|
Overall Width |
74 in |
Gearbox HP |
50 |
|
Overall Height |
35 in |
Number of Y Blades |
/ |
|
Working Width |
69 in |
Number of Hammers |
28 |
|
32 / 37 in |
PTO Speed |
540 rpm |
|
|
18 / 51 in |
3-Point Linkage |
CAT I , CAT II |
|
|
Transmission: RPM Rotor speed |
2,340 |
Belts Quantity |
3 |
|
A (Rotor: diameter) |
Φ4 x 0.3 in |
Belt Tension Adjustable |
Manual |
|
B (Rotation diameter of the cutting edge) |
14 in |
Weight (PTO Shaft Included) |
822 lbs |
|
C (Distance from the center of the rotor to the top of the inner side of the hood) |
8 in |
Tractor Power Range |
25-65 HP |
|
D(Rear roller: diameter) |
Φ4 x 0.16 in |
Gearbox Oil Type |
SAE90 EP Gear Oil |
|
Packing Sizes |
76 x 35 x 30 in |
||
|
V ft/s |
144 |
Packaging Weight |
911 lbs |
|
Openable maintenance door |
NO |
