Description
|
Overall Length |
42 in |
RAM |
YES |
|
Overall Width |
96 in |
Gearbox HP |
50 |
|
Overall Height |
37 in |
||
|
Working Width |
87 in |
Number of Hammers |
28 |
|
42 / 45 in |
Transmission: PTO |
540 |
|
|
24 / 63 in |
3 Point Linkage |
I II |
|
|
Transmission: RPM Rotor speed |
2,146 |
Belts Quantity |
4 |
|
A (Rotor: diameter) |
φ7 x 0.3 in |
Belt Tension Adjustable |
Manual |
|
B (Rotation diameter of the cutting edge) |
16 in |
Weight （INCLUDED PTO SHAFT） |
1,404 lbs |
|
C (Distance from the center of the rotor to the top of the inner side of the hood) |
9 in |
Tractor Power Range |
30-85 HP |
|
D(Rear roller: diameter) |
φ6 x 0.2 in |
Gearbox Oil Type |
SAE90 EP Gear Oil |
|
Packing sizes |
98 x 48 x 41 in |
||
|
Tip speed (approx.) |
**151 ft/s** |
Packaging weight |
1,592 lbs |
|
Openable maintenance door |
YES |
