TOP OF THE LINE
The Bad Boy Renegade Diesel is our top dog, top-of-the line zero-turn mower. This beast is powered by a Perkins 1100cc diesel engine that delivers more torque and more horsepower. Its dual 16cc Hydro-Gear Pumps with 18ci Parker Wheel Motors are preferred by professionals. The Renegade Diesel’s exclusive automotive-inspired dual pump belt system with tensioner design evenly distributes load from the crankshaft between pump drives and deck belts, improving belt life up to 50% longer. And the Renegade Diesel’s 13-gallon fuel capacity (with simultaneous dual feed tanks) provides better balance and all-day mowing. There’s simply no better commercial-grade zero-turn mower for the demanding lawncare professional or large-acre homeowner. It’s built Bad Boy tough, made to outlast, outperform and out-cut the competition.
A REVELUTIONARY 3-LINK SUSPENSION
Bad Boy’s industry-changing 3-link rear trailing arm suspension – matched with patented independent cast front I-beam suspension rails – provides for a smoother ride, more consistent tire contact with the terrain and increased hillside stability. Our suspension systems absorb the impact, not you. We like to say it’s the best ride in the business.
UNRIVALED TOUGHNESS
The Bad Boy Renegade Diesel Zero-Turn Mower is brute strength and pure performance combined. Its heavy-gauge, all-steel, all-welded and fabricated 1.5˝ x 3˝ frame rail provides the backbone for years of durable service. And it’s sporting the heaviest deck of any commercial mower in the industry, made with 3-gauge, ¼” fabricated steel and reinforced 3/8˝ sides. Plus it features patented Dual Deck Support Isolators, with deck wear pad, to help minimize damage from side impacts. Our deck idler arm and spring with bearings maintains consistent tension and cutting speed. And the Renegade Diesel features PEER maintenance-free, internally lubricated spindles, plus larger sized, no-flat front tires and our exclusive Reaper® rear tires for maximum traction. If you want long-lasting, no-nonsense performance, this is the Bad Boy for you.
RIDE IN STYLE AND COMFORT
The Renegade Diesel is not just about power, it’s also about the ride. The Renegade Diesel’s throne is a suspension seat, fully adjustable to operator weight and height with variable rate suspension, lumbar support and back adjustments from from 5° to 15°. The Renegade Diesel also features a new floorboard mat and square drive arms and grips for a better drive experience. Our unique deck lift pedal can be changed to either side and locked in place with a quick twist of our deck lift dial. There’s even a key fob start with digital diagnostic display. Sporty, strong, and still the most comfortable ride on a mower, that’s the Bad Boy Renegade Diesel Zero-Turn Mower.
Bad Boy Accessory Compatibility Chart |
R-Series Rebel, Rogue & Renegade Accessories
|
|
| Advanced Chute System 54″ Deck | 088-5419-00 |
| Advanced Chute System 61″ & 72″ Deck | 088-6000-00 |
| Caster Brake Kit | 088-2014-00 |
| Electric Actuator Kit for Rebel & Rogue Models | 035-7033-01 |
| Electric Actuator Kit for Renegade Models | 035-7033-02 |
| Rear Mount Storage Basket (Does NOT fit Renegade) | 088-4055-00 |
| Loading Ramps, 21″ x 64″ | 088-1076-00 |
| Adjustable Handles | 031-9060-18 |
| Armrest Assembly | 071-2023-00 |
| Mower Cover | 088-3050-00 |
| Dual Front LED Lights | 088-1007-00 |
| Seat Isolation Kit | 088-0500-00 |
Mount Assist Handle |
|
| 2″ Receiver Assist Handle | 088-3503-98 |
| 2″ Receiver Step | 088-3520-00 |
| 2″ Receiver Step & Handle | 088-3515-00 |
| R-Series Mount Assist Handle | 088-3505-00 |
Mulching Kits |
|
| 54″ R-Series Mulch Kit with Blades | 210-0354-00 |
| 61″ R-Series Mulch Kit with Blades | 210-0361-00 |
| 72″ R-Series Mulch Kit with Blades | 210-0372-00 |
| 72″ Rear Discharge Mulch Kit with Blades | 026-0343-00 |
R-Series Tank Light Kit |
|
| R-Series Tank Light Kit | 088-0998-00 |
Wheel Covers |
|
| 6″ Wheel Covers (Pair) | 088-1079-00 |
| 12″ Wheel Covers (1 Cover) | 088-1085-00 |
Seats |
|
| Rebel & Rebel X Replacement Seat | 071-6065-25 |
| Rogue Replacement Seat | 071-6065-25 |
| Renegade Replacement Seat | 071-6065-25 |
ROPS Kits |
|
| ROPS Weed Eater Rack | 088-0300-00 |
| ROPS Caution Light Kit | 088-0999-00 |
| ROPS Sound bar w/ 2×2 clamps & hardware | 088-2800-00 |
| ROPS LED Light Kit w/ 2×2 Mount Hardware | 088-1000-10 |
| ROPS Hard Top Canopy | 088-1025-00 |
Bagging Systems |
|
| Bad Boy 3 Bagger System 54″ Rebel & Rogue | 092-4004-23 |
| Bad Boy 3 Bagger System 61″ Rebel & Rogue | 092-4009-23 |
| Bad Boy 3 Bagger System 72″ Rebel & Rogue | 092-4011-23 |
| Bad Boy 3 Bagger System 61″ Renegade | 092-4008-23 |
| Bad Boy 3 Bagger System 72″ Renegade | 092-4010-23 |
Hitch Kits & Related Accessories |
|
| 2019+ R-Series Hitch Assembly (Bolt On, Slide In, Pin) | 093-1129-00 |
| 2019+ R-Series Hitch | 093-1128-00 |
| Receiver Hitch (Slide In) | 093-1111-00 |
| Bent Hitch Pin for Slide in Hitch | 044-5005-00 |
| Front Mount Tool Box | 088-4025-00 |
| Front Mount Cargo Basket | 088-4020-00 |
| Front Mount Sprayer Only-15 Gallon Tank, 51″ Boom | 088-1001-00 |
| Front Mount Sprayer Holding Plate | 026-4000-00 |
| Bucket and Tongs | 088-0201-00 |
Canopies |
|
| Hard Top Canopy | 088-1025-00 |
Turf Tires (New) |
|
| 24x12x12 Turf Tire | 022-4123-00 |
| 26x12x12 Turf Tire | 022-4023-00 |
Chevron Tires Only (Bar Lug) |
|
| 24x12x12 (Tire only Each) (Rebel) | 022-5500-00 |
| 26x12x12 (Tire only Each) – (Rogue and Renegade Only) | 022-7050-00 |
Field Trax Tires |
|
| 24x12x12 Field Trax Tires (Rebel) | 022-5452-00 |
| 26x12x12 Field Trax Tires (Rogue & Renegade Only) | 022-7070-00 |
Michelin Tweels (Each) |
|
| Michelin Tweel 24x12x12 Rebel | 022-4092-00 |
| Michelin Tweel 26x12x12 Rouge & Renegade (Excludes Diesel) | 022-4093-00 |
| Michelin Tweel 22x11x12 | 022-4096-00 |
| Michelin Front Tweel 13×6.5×6 | 022-0006-98 |
R-Series Black Aluminum Wheel (pair) |
|
| Black Vector Rebel All & Rogue 54 (Wheels only) | 022-4203-75 |
| Black Vector Rogue & Renegade (Wheels only) Excludes Rouge 54 | 022-4204-02 |
Snow Plows |
|
| 60″ Snow Plow | 088-1043-00 |
| 72″ Snow Plow | 088-1044-00 |
Pull Behind Mower Accessories (Requires hitch kit) |
|
| Pull-Behind Utility Trailer | 088-0800-00 |
| Pull-Behind Roller | 088-2065-00 |
| Pull-Behind De-thatcher | 088-2070-00 |
| Pull-Behind Sweeper | 088-1028-00 |
| Pull-Behind Lawn Sweeper | 088-0600-00 |
| Pull-Behind Aerator | 088-2075-00 |
| Pull-Behind Sprayer | 088-1012-00 |
| Sprayer Boom | 088-1013-00 |
Bumper Kits |
|
| 8″ Bumper Kit | 029-7038-00 |
| 14″ Bumper Kit | 029-7037-00 |
Paint |
|
| Touch Up Spray | 082-1001-00 |
| Touch Up Paint | 082-1002-00 |
| Touch Up Pen | 082-1003-00 |
Mower Lifts |
|
| Mo Jack Pro Series | 090-2000-00 |
| Mo Jack EZ Series | 090-2005-00 |
| Mo Jack XT Series | 090-2006-00 |
| Ohio Steel Mower Lift | 090-5000-00 |
___________________________________________________________________________
Specifications:
Renegade Engine |
|
| Perkins | 61″ – 1100cc, 24.7 hp 1.1L 3 Cylinder |
Renegade Dimensions |
|
| Cutting Width | 61″ |
| Weight | 61″ – 1,862 lbs. |
| Height / Length | 51″/91″ |
| Chute Up / Chute Down Width | 61″ – 63.5″/75.5″ |
Renegade Features |
|
| Suspension | Patented 3-Link Rear Trailing Arm Suspension with Patented Front Independent Suspension |
| Transmission | Hydro-Gear® 16cc Pump; Parker® 18ci Wheel Motors |
| Deck Thickness | 1/4″ or 3-Gauge Thick Solid Steel |
| Cutting Height | 2″ – 6″ |
| Lift & Height Adjustment | Foot-Assist Manual Lift with Dial-Style Height Adjustment. Optional Electric Lift. |
| Rear Tires / Front Tires | 26×12-12 Reaper® / 15×6-6 Smooth No Flat Front |
| Fuel | 13 Gallons, Unleaded Gasoline |
| Ground Speed (Forward) | Up To 13 mph |
